Oracle Data Pump Import (IMPDP): A Complete Guide

Oracle Data Pump Import (IMPDP) is a robust utility provided by Oracle for importing data and metadata into an Oracle database. Designed to be more efficient and flexible than traditional import utilities, IMPDP supports advanced features such as parallel processing, data transformations, and remapping. It is commonly used to restore data from logical backups or migrate data between databases.

IMPDP Command Syntax

nohup impdp '"/ as sysdba"' DIRECTORY=directory_name
  DUMPFILE=dumpfile_name.dmp [,dumpfile_name2.dmp, dumpfile_name3.dmp, ...]
  LOGFILE=logfile_name.log
  FULL=Y|N
  SCHEMAS=schema_name [,schema_name]
  TABLES=table_name [,table_name] or owner1.tablename, owner2.tablename
  INCLUDE=object_type [,object_type]
  EXCLUDE=object_type [,object_type]
  CONTENT=ALL|DATA_ONLY|METADATA_ONLY
  FLASHBACK_SCN=scn_number
  FLASHBACK_TIME="timestamp"
  NETWORK_LINK=network_link_name
  REMAP_SCHEMA=old_schema:new_schema
  REMAP_TABLESPACE=old_tablespace:new_tablespace
  TRANSPORTABLE=ALWAYS|AUTOMATIC|NEVER
  COMPRESSION=ALL|DATA|METADATA|NONE
  ESTIMATE_ONLY=Y|N
  PARALLEL=number_of_threads
  QUERY=table_name:"WHERE condition"
  REUSE_DATAFILES=Y|N
  ROWS=Y|N
  TABLESPACES=tablespace_name [,tablespace_name]
  VERSION=version_number
  JOB_NAME=job_name
  ENCRYPTION=ALL|DATA|METADATA|NONE
  ENCRYPTION_ALGORITHM=algorithm_name
  ENCRYPTION_PASSWORD=password
  ENCRYPTION_TRANSFORM=transform_name
  LOGTIME=ALL|NONE|DATE
  DATA_OPTIONS=option [,option]
  TRANSFORM=transform_option [,transform_option]
  DISABLE_ARCHIVE_LOGGING=Y|N
  RAC=Y|N &

Example IMPDP Command

Below is a practical example demonstrating the use of multiple parameters in an IMPDP command:

nohup impdp '"/ as sysdba"' DIRECTORY=my_dump_dir
  DUMPFILE=my_dumpfile_%U.dmp,my_dumpfile_%U_%I.dmp
  LOGFILE=my_import.log
  FULL=N
  SCHEMAS=hr,sales
  TABLES=employees,departments or owner1.tablename, owner2.tablename
  INCLUDE=TABLE:"IN ('EMPLOYEES', 'DEPARTMENTS')"
  EXCLUDE=TABLE:"IN ('TEMP_TABLES')"
  CONTENT=ALL
  FLASHBACK_SCN=123456789
  FLASHBACK_TIME="2024-08-20 12:00:00"
  NETWORK_LINK=my_remote_db_link
  REMAP_SCHEMA=old_hr:new_hr
  REMAP_TABLESPACE=old_tablespace:new_tablespace
  TRANSPORTABLE=AUTOMATIC
  COMPRESSION=ALL
  ESTIMATE_ONLY=N
  PARALLEL=4
  QUERY=employees:"WHERE department_id=10"
  REUSE_DATAFILES=N
  ROWS=Y
  TABLESPACES=users,system
  VERSION=19
  JOB_NAME=my_import_job
  ENCRYPTION=DATA
  ENCRYPTION_ALGORITHM=AES256
  ENCRYPTION_PASSWORD=my_password
  ENCRYPTION_TRANSFORM=PASSWORD
  LOGTIME=DATE
  DATA_OPTIONS=ROWS
  TRANSFORM=DISABLE_ARCHIVE_LOGGING:Y,CONSTRAINTS:N
  DISABLE_ARCHIVE_LOGGING=Y|N
  RAC=Y &

Parameters and Descriptions

Essential Parameters

• DIRECTORY: Directory object where dump files are located.
  Example: DIRECTORY=my_dump_dir
• DUMPFILE: Specifies the dump file(s) to be imported.
  • Single file: dumpfile_name.dmp
  • Multiple files with suffixes: dumpfile_name_%U.dmp or dumpfile_name_%U_%I.dmp
    Example: DUMPFILE=my_dumpfile_%U.dmp,my_dumpfile_%U_%I.dmp
• LOGFILE: Name of the log file to record import details.
  Example: LOGFILE=my_import.log
• FULL: Indicates whether to import the entire database (Y) or a subset (N).
  Example: FULL=N
• SCHEMAS: List of schemas to import.
  Example: SCHEMAS=hr,sales
• TABLES: List of tables to import.
  Example: TABLES=employees,departments or owner1.table1,owner2.table2

Data Filtering

• INCLUDE: Object types to include in the import.
  Example: INCLUDE=TABLE:"IN ('EMPLOYEES', 'DEPARTMENTS')"
• EXCLUDE: Object types to exclude from the import.
  Example: EXCLUDE=TABLE:"IN ('TEMP_TABLES')"
• QUERY: SQL condition to filter data during import.
  Example: QUERY=employees:"WHERE department_id=10"

Advanced Features

• REMAP_SCHEMA: Remaps objects from one schema to another.
  Example: REMAP_SCHEMA=old_hr:new_hr
• REMAP_TABLESPACE: Remaps objects to a different tablespace.
  Example: REMAP_TABLESPACE=old_tablespace:new_tablespace
• TRANSPORTABLE: Enables transportable tablespaces mode (ALWAYS, AUTOMATIC, NEVER).
  Example: TRANSPORTABLE=AUTOMATIC
• COMPRESSION: Compression type for the data being imported.
  Example: COMPRESSION=ALL

Performance and Parallelism

• PARALLEL: Number of threads for parallel import.
  Example: PARALLEL=4
• ROWS: Imports data rows (Y) or metadata only (N).
  Example: ROWS=Y
• DISABLE_ARCHIVE_LOGGING: Suppresses redo generation during import.
  Example: DISABLE_ARCHIVE_LOGGING=Y
• ESTIMATE_ONLY: Estimates the size without performing the import (Y or N).
  Example: ESTIMATE_ONLY=N

Security Features

• ENCRYPTION: Specifies the encryption type for the import.
  Example: ENCRYPTION=DATA
• ENCRYPTION_ALGORITHM: Defines the algorithm for encryption.
  Example: ENCRYPTION_ALGORITHM=AES256
• ENCRYPTION_PASSWORD: Password used for encryption.
  Example: ENCRYPTION_PASSWORD=my_password

Logging and Debugging

• LOGTIME: Adds timestamps to log entries (ALL, DATE, NONE).
  Example: LOGTIME=DATE
• DATA_OPTIONS: Additional options for handling data.
  Example: DATA_OPTIONS=ROWS
• JOB_NAME: Specifies a custom name for the import job.
  Example: JOB_NAME=my_import_job

Oracle Data Pump Import is a versatile and high-performance utility for managing imports in Oracle databases. By understanding the key parameters and their configurations, you can efficiently restore or migrate data to meet your requirements.
